• Inverter duty insulation system
• Constant HP range at 2x base speed 56 - 256T frames
• Constant HP range at 1.5x base speed 284T - 445T frames
• No mounting available for encoder devices
• Normally closed thermostats
• Steel and aluminum frame construction - see notes
• Precision balanced rotors

Nameplate Specifications

Phase	3
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	230/460 V
Speed	1750 rpm
Service Factor	1.0
Frame	56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Thermostat
Efficiency	68 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.4/1.2 A
Power Factor	61.1
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	M
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	40 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	11.81 in
Frame Length	6.56 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 4:1

General Specifications

UPC	691720988862
Weight	24.00 LB
Packaged Length	16.38 IN
Packaged Width	10.50 IN
Packaged Height	8.12 IN
Country of Origin	Mexico
