• Nameplated 190-200-208/380-400-416
• 12 Lead delta capability
• Ball bearings
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	2 Hp
Output KW	1.5 kW
Voltage	220/380 V
Speed	1425 rpm
Service Factor	1.15
Frame	145T
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	81.5 %
Ambient Temperature	40 °C
Frequency	50 Hz
Current	6.4,3.7 A
Power Factor	0
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	G
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Three Phase
Starting Method	N/R
Poles	4
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	14.23 in
Frame Length	9.63 in
Shaft Diameter	0.880 in
Shaft Extension	2.25 in

General Specifications

UPC	722856043597
Weight	40.00 LB
Packaged Length	16.12 IN
Packaged Width	10.25 IN
Packaged Height	9.12 IN
HTC	8501.52.4000
Country of Origin	Mexico
