• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	220/380 V
Speed	1425 rpm
Service Factor	1.25
Frame	56
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	66.7 %
Ambient Temperature	40 °C
Frequency	50 Hz
Current	3.0,1.7 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	P
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Three Phase
Starting Method	N/R
Poles	4
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	10.05 in
Frame Length	5.72 in
Shaft Diameter	0.630 in
Shaft Extension	1.88 in

General Specifications

UPC	722856010315
Weight	21.00 LB
Packaged Length	13.69 IN
Packaged Width	7.13 IN
Packaged Height	7.50 IN
HTC	8501.51.4040
Country of Origin	Mexico
