• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Class B or F Insulation protects motor for a maximum temperature rating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	208-230/460 V
Speed	1140 rpm
Service Factor	1.15
Frame	56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	76.1 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.9-2.8 A
Power Factor	0
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	K
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Three Phase
Starting Method	N/R
Poles	6
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	Any
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Overall Length	12.44 in
Frame Length	7.15 in
Shaft Extension	.625 X 1.88 - .188 X .188 KEY in

General Specifications

Weight	31.00 LB
Packaged Length	15.44 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
Country of Origin	Mexico
