• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Class B or F Insulation protects motor for a maximum temperature rating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	208-230/460 V
Speed	1140 rpm
Service Factor	1.15
Frame	143TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	76.1 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.9-2.8,1.4 A
Power Factor	0
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	K
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Three Phase
Starting Method	N/R
Poles	6
Rotation	Counterclockwise/Clockwise
Mounting	Round
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	12.56 in
Frame Length	7.15 in
Shaft Diameter	0.880 in
Shaft Extension	2 in

General Specifications

UPC	722856015211
Weight	31.00 LB
Packaged Length	15.14 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
HTC	8501.51.4040
Country of Origin	Mexico
