• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	0.75 & 0.50 Hp
Output KW	0.56 & 0.37 kW
Voltage	230/460 & 190/380 V
Speed	1140 & 950 rpm
Service Factor	1.15 & 1.15
Frame	56C
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	81.7 & 82.5 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	3.5/1.75 & 3.4/1.7 A
Power Factor	50.9
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	M
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	12
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	6
Rotation	Reversible
Resistance Main	16.3 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	14.00 in
Frame Length	8.25 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 OUT ODE BRKT RADIAL

General Specifications

UPC	722856117847
Weight	42.10 LB
Packaged Length	15.44 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
HTC	8501.51.4040
Country of Origin	Mexico
