• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	208-230/460 V
Speed	1140 rpm
Service Factor	1.25
Frame	56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	0 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.3-4.5 A
Duty	Continuous
Insulation Class	B
KVA Code	R
Drive End Bearing Size	6205
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Three Phase
Starting Method	N/R
Poles	6
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	BALL
Frame Material	Rolled Steel
Overall Length	13.72 in
Frame Length	8.43 in
Shaft Extension	.625 X 1.88 - .188 X .188 KEY in

General Specifications

UPC	722856055330
Weight	39.28 LB
Packaged Length	15.44 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
HTC	8501.52.4000
Country of Origin	Mexico
