• Heavy gauge steel frame and base
• Economical split phase design
• Shaft extension 1-1/2" long by 1/2" diameter
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	110/220 V
Speed	1425 rpm
Service Factor	1
Frame	48
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	59.5 %
Ambient Temperature	40 °C
Frequency	50 Hz
Current	7.0,3.5 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	P
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase
Starting Method	SM
Poles	4
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	9.66 in
Frame Length	6.22 in
Shaft Diameter	0.500 in
Shaft Extension	1.5 in

General Specifications

UPC	722856007087
Weight	17.00 LB
Packaged Length	12.63 IN
Packaged Width	6.94 IN
Packaged Height	7.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
