• Meets or exceeds NEMA Premium® efficiency. Model is in compliance with EISA2007
• Inverter Duty 10:1 Variable Torque and 2:1 Constant Torque
• Nameplated 60/50 hertz, 190/380 volts at next lower HP
• F1 mounting only, cannot reassemble to F2
• Drip cover included
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	2 & 1.50 Hp
Output KW	1.5 & 1.1 kW
Voltage	230/460 & 190/380 V
Speed	3510 & 2930 rpm
Service Factor	1.15 & 1.0
Frame	145JMV
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	86.5 & 85.5 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	5.6/2.8 & 5/2.5 A
Power Factor	78.5
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6206
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	2
Rotation	Reversible
Resistance Main	7.6 Ohms
Mounting	Round
Motor Orientation	Horizontal Or Shaft Down
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	JM
Overall Length	13.42 in
Frame Length	7.06 in
Shaft Diameter	0.875 in
Shaft Extension	4.25 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 2:1

General Specifications

UPC	722856003355
Weight	33.00 LB
Packaged Length	15.50 IN
Packaged Width	14.00 IN
Packaged Height	9.38 IN
HTC	8501.52.4000
Country of Origin	Mexico
