• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Suitable for use on a VFD, 10:1 variable torque and 2:1 constant torque.
• Class F insulation(as noted) protects motor for a maximum temperature rating.
• 1.15 service factor on sinewave, 1.0 service factor on IGBT power.
• Double sealed ball bearings mechanically locked on shaft end.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	1 & 0.75 Hp
Output KW	0.75 & 0.56 kW
Voltage	208-230/460 & 190/380 V
Speed	1760 & 1460 rpm
Service Factor	1.15 & 1.0
Frame	143JMV
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	85.5 & 85.3 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	3.2-3/1.5 & 3/1.5 A
Power Factor	71
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	N
Drive End Bearing Size	6206
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	13.6 Ohms
Mounting	Round
Motor Orientation	Horizontal Or Shaft Down
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	JM
Overall Length	15.42 in
Frame Length	9.06 in
Shaft Diameter	0.875 in
Shaft Extension	4.25 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 2:1

General Specifications

UPC	722856003171
Weight	45.00 LB
Packaged Length	19.00 IN
Packaged Width	10.88 IN
Packaged Height	9.75 IN
HTC	8501.52.4000
Country of Origin	Mexico
