• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Class B or F Insulation protects motor for a maximum temperature rating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	1.50 & 1.50 Hp
Output KW	1.1 & 1.1 kW
Voltage	230/460 & 190/380 V
Speed	1725 & 1425 rpm
Service Factor	1.15 & 1.15
Frame	56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	86.5 & 85.5 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	4.6/2.3 & 5.4/2.7 A
Power Factor	71
Duty	Continuous
Insulation Class	B
Design Code	A
KVA Code	P
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	7.9 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	14.65 in
Frame Length	9.15 in
Shaft Diameter	0.625 in
Shaft Extension	2.06 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856051493
Weight	44.00 LB
Packaged Length	19.31 IN
Packaged Width	11.19 IN
Packaged Height	9.75 IN
Country of Origin	Mexico
