Nameplate Specifications

Phase	3
Output HP	5 Hp
Output KW	3.7 kW
Voltage	575 V
Speed	3490 rpm
Service Factor	1.00
Frame	145TC
Enclosure	Drip Proof
Thermal Protection	Thermostat
Efficiency	84 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.0 A
Power Factor	90
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	2
Rotation	Reversible
Resistance Main	.73 Ohms
Mounting	Bolt-on Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Assembly/Box Mounting	F1 ¿ F2/F3 CAPABLE
Inverter Load	VARIABLE 10:1

General Specifications

UPC	691720116128
Country of Origin	Mexico
