• Double-shielded bearings extend the service life of the motor.
• EXXON® Polyrex® EM Grease supports extreme temperatures between -20°F(-29 ˚ C) and +350°F(+177˚C).
• Shaft flingers protect bearings from damage caused by dirt and rain.
• Condensation drains allow the motor to expel and drain built-up moisture.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	115/230 V
Speed	1725 rpm
Service Factor	1.15
Frame	56
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Manual
Efficiency	57.2 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	7.8 A
Power Factor	0
Duty	Continuous
Insulation Class	B
Design Code	O
KVA Code	R
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor start(CSIR)
Starting Method	SM
Poles	4
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	Any
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Overall Length	11.00 in
Frame Length	5.72 in
Shaft Extension	.625 X 1.88 - .188 X .188 KEY in

General Specifications

Weight	22.00 LB
Packaged Length	15.44 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
Country of Origin	Mexico
