• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Suitable for belt-driven or fan-on-shaft applications.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	230/460 V
Speed	1150 rpm
Service Factor	1.15
Frame	145T
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	82.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.6/1.8 A
Power Factor	63
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	6
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Cast Iron
Shaft Type	T
Assembly/Box Mounting	F1/F2 CAPABLE
Inverter Load	CONSTANT 10:1

General Specifications

UPC	722856078568
Weight	69.00 LB
Packaged Length	15.50 IN
Packaged Width	14.00 IN
Packaged Height	9.38 IN
Country of Origin	Mexico
