• Mechanically locked on shaft end
• Heavy gauge steel frame and base
• Capacitor start design for high starting torque
• Capacitor start/capacitor run design for higher efficiency, as noted
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.33 & 0.33 Hp
Output KW	0.25 & 0.25 kW
Voltage	120/240 & 120/240 V
Speed	1725 & 1425 rpm
Service Factor	1.35 & 1.35
Frame	56C
Enclosure	Drip Proof
Thermal Protection	Manual
Efficiency	72.4 & 66 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	3.65/1.8 & 4.8/2.6 A
Power Factor	79
Duty	Continuous
Insulation Class	B
Design Code	N
KVA Code	L
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	No
CSA	Y
CE	Y
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	10.94 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856055941
Weight	21.00 LB
Packaged Length	16.38 IN
Packaged Width	10.50 IN
Packaged Height	9.62 IN
HTC	8501.40.4040
Country of Origin	Mexico
