• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Class B or F Insulation protects motor for a maximum temperature rating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	200 V
Speed	1750 rpm
Service Factor	1.15
Frame	145T
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	86.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.2 A
Power Factor	67.7
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	1.8 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	13.43 in
Frame Length	7.50 in
Shaft Diameter	0.875 in
Shaft Extension	2.38 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856016522
Weight	34.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
HTC	8501.52.4000
Country of Origin	United States of America
