• Double sealed ball bearings, mechanically locked on shaft end
• Designed for 50 Hz operation
• Fixed CW rotation, viewed opposite shaft end
• Automatic reset thermal protector
• 56C = carbon steel shaft with key
• 56J = 416 stainless steel threaded shaft with slinger
• Drip cover not included, see Accessories Section
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	115/208-230 V
Speed	1725 rpm
Service Factor	1.35
Frame	56J
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	59.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.0,3.2-3.0 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	M
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	SM
Poles	4
Rotation	Clockwise
Mounting	Round
Motor Orientation	ANY
Drive End Bearing	LOCKED
Opp Drive End Bearing	BALL
Frame Material	Rolled Steel
Overall Length	10.82 in
Frame Length	6.22 in
Shaft Diameter	0.630 in
Shaft Extension	2.39 in

General Specifications

UPC	722856032171
Weight	17.00 LB
Packaged Length	12.63 IN
Packaged Width	6.94 IN
Packaged Height	7.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
