• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power. specifications
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Capacitor start design optimizes motor torque and efficiency performance.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1
Frame	56
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Manual
Efficiency	73 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	16.4,8.2 A
Power Factor	0
Duty	Continuous
Insulation Class	B
Design Code	J
KVA Code	H
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	SM
Poles	2
Rotation	Counterclockwise/Clockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	BALL
Frame Material	Rolled Steel
Overall Length	12.96 in
Frame Length	7.68 in
Shaft Diameter	0.630 in
Shaft Extension	1.88 in

General Specifications

UPC	722856008701
Weight	35.00 LB
Packaged Length	15.14 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
HTC	8501.40.6040
Country of Origin	Mexico
