• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.25
Frame	48
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	62 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	7.6 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	L
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor start(CSIR)
Starting Method	SM
Poles	2
Rotation	Counterclockwise/Clockwise
Mounting	Resilient Base
Motor Orientation	Any
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Overall Length	10.00 in
Frame Length	6.22 in
Shaft Diameter	0.500 in
Shaft Extension	.500 X 1.50 FLAT in

General Specifications

UPC	722856078438
Weight	17.00 LB
Packaged Length	13.69 IN
Packaged Width	7.13 IN
Packaged Height	7.50 IN
Country of Origin	Mexico
