• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	1 Hp
Output KW	0.75 kW
Voltage	115/208-230 V
Speed	1725 rpm
Service Factor	1.15
Frame	56
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	82.6 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	8.0/4.4-4.0 A
Power Factor	96
Duty	Continuous
Insulation Class	B
Design Code	N
KVA Code	K
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	2.12 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	12.49 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856056122
Weight	38.48 LB
Packaged Length	15.49 IN
Packaged Width	9.69 IN
Packaged Height	11.19 IN
HTC	8501.40.6040
Country of Origin	Mexico
