• Two-compartment design for easy servicing
• Not for use in pool pump applications
• 50° C Ambient
• Fixed CW rotation, viewed opposite shaft end
• C-Face Footless, 56C/56J
• Capacitor start induction run design
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.5
Frame	56J
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	69.5 %
Ambient Temperature	50 °C
Frequency	60 Hz
Current	13.0,6.5 A
Power Factor	70.3
Duty	Continuous
Insulation Class	B
KVA Code	N
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	None
CE	N
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	SM
Poles	2
Rotation	Clockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	LOCKED
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	12.52 in
Frame Length	6.87 in
Shaft Diameter	0.630 in
Shaft Extension	2.57 in

General Specifications

UPC	722856081827
Weight	24.00 LB
Packaged Length	15.44 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
Country of Origin	Mexico
