• Two-compartment design for easy servicing
• Not for use in pool pump applications
• Capacitor start induction run design
• Fixed CW rotation, viewed opposite shaft end
• Square Flange
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.9
Frame	56Y
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	64.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	10.8,5.4 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	L
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	SM
Poles	2
Rotation	Clockwise
Mounting	Round
Motor Orientation	ANY
Drive End Bearing	LOCKED
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	11.59 in
Frame Length	6.22 in
Shaft Diameter	0.630 in
Shaft Extension	0.265 in

General Specifications

UPC	722856031945
Weight	17.00 LB
Packaged Length	17.69 IN
Packaged Width	7.69 IN
Packaged Height	7.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
