• Ball bearings (except as noted)
• Heavy gauge steel constructions
• Thermal protection, as noted
• Capacitor start design for high starting torque
• Capacitor start/capacitor run design for higher efficiency, as noted
• Service Factor, as noted
• UL Recognized and CSA Certified

Nameplate Specifications

Phase	1
Output HP	2 Hp
Output KW	1.5 kW
Voltage	115/208-230 V
Speed	1725 rpm
Service Factor	1.15
Frame	56H
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	77.1 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	22.0 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run(CSCR)
Starting Method	SM
Poles	4
Rotation	Counterclockwise/Clockwise
Mounting	Resilient Base
Motor Orientation	Any
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Overall Length	13.96 in
Frame Length	9.63 in
Shaft Extension	.625 X 1.88 - .188 X .188 KEY in

General Specifications

Weight	44.00 LB
Packaged Length	15.44 IN
Packaged Width	10.19 IN
Packaged Height	9.50 IN
Country of Origin	Mexico
