• Standard efficient ratings
• Inverter-rated; Continuous duty
• Class B insulation systems – 42, 48 and 56 frames
• Shielded ball bearings for direct coupled applications Contact your local sales office for belted load applications
• Dynamically balanced rotors
• Dynamically balanced rotors
• Torques exceed NEMA performance standards
• UL recognized and CSA certified

Nameplate Specifications

Phase	1
Output HP	3 Hp
Output KW	2.2 kW
Voltage	230 V
Speed	3510 rpm
Service Factor	1
Frame	145T
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	84 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	11.8 A
Power Factor	99.2
Duty	Continuous
Insulation Class	B
Design Code	NO DESIGN CODE
KVA Code	H
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Assembly/Box Mounting	F1 ONLY

General Specifications

Weight	51.00 LB
Packaged Length	12.87 IN
Packaged Width	6.50 IN
Packaged Height	7.34 IN
Country of Origin	Mexico
