• Automatic reset thermal(as noted) protector prevents overheating.
• Shielded ball bearings extend the service life of the motor.
• Class B insulation protects motor for a maximum temperature rating.
• Suitable for indoor or outdoor applications(as noted).
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	1 Hp
Output KW	0.75 kW
Voltage	230 V
Speed	825 rpm
Service Factor	1.1
Frame	56CZ
Enclosure	Totally Enclosed Air Over
Thermal Protection	Automatic
Efficiency	64 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.2 A
Power Factor	98
Duty	Continuous
Insulation Class	B
Design Code	N
KVA Code	A
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor
Starting Method	Across The Line
Poles	8
Rotation	Fixed Counterclockwise
Resistance Main	3.8 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Overall Length	13.44 in
Frame Length	9.56 in
Shaft Diameter	0.750 in
Shaft Extension	3.5 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720053874
Weight	47.00 LB
Packaged Length	19.69 IN
Packaged Width	12.62 IN
Packaged Height	12.31 IN
Country of Origin	Mexico
