• UL recognized component listing and CSA certification ensures the product is safe for use.
• High starting torque on start-up, to achieve a higher starting load required in air compressor applications.
• Capacitor start or capacitor run for low-amp, high-efficiency, as noted.
• Heavy-duty construction ensures motor durability.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	2 Hp
Output KW	1.5 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1
Frame	56
Enclosure	Drip Proof
Thermal Protection	Manual
Efficiency	79.1 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	15.0,7.5 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	G
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	SM
Poles	2
Rotation	Clockwise/Counterclockwise
Mounting	Rigid Base
Motor Orientation	ANY
Drive End Bearing	BALL
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	12.76 in
Frame Length	8.43 in
Shaft Diameter	0.630 in
Shaft Extension	1.88 in

General Specifications

UPC	722856048226
Weight	38.00 LB
Packaged Length	12.66 IN
Packaged Width	6.46 IN
Packaged Height	8.18 IN
HTC	8501.40.6040
Country of Origin	Mexico
