• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double shielded ball bearings provide longer service life.
• Continuous or continuous air over duty design allows consistent operation at the rated power(as noted).
• Various mounting configurations (as noted).
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	115 V
Speed	1725 rpm
Service Factor	1
Frame	48N
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	Manual
Efficiency	0 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.8 A
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	N
Drive End Bearing Size	.500
Opp Drive End Bearing Size	.500
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase
Starting Method	SM
Poles	4
Rotation	Clockwise/Counterclockwise
Mounting	N/R
Motor Orientation	Any
Drive End Bearing	Sleeve
Opp Drive End Bearing	Sleeve
Overall Length	8.13 in
Frame Length	5.16 in
Shaft Extension	N/R in

General Specifications

Packaged Length	12.63 IN
Packaged Width	6.94 IN
Packaged Height	7.50 IN
Country of Origin	Mexico
