• BISSC certified for the Baking Industry
• Stainless Steel Output shafts
• Repositionable drain plugs for all angle mounting
• Double Sealed bearings
• Output shaft seal
• Inverter Duty IRIS™ insulation system
• Laser etched full-fact nameplate on frame
• All Stainless exterior
• Anti-corrosion coating applied to interior components

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115/230 V
Speed	1145 rpm
Service Factor	1
Frame	48YZ
Enclosure	Totally Enclosed Air Over
Thermal Protection	Automatic
Efficiency	64 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.4/2.7 A
Power Factor	94
Duty	Continuous
Insulation Class	F
Design Code	NO DESIGN CODE
KVA Code	E
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor
Starting Method	Across The Line
Poles	6
Rotation	Selective Clockwise
Resistance Main	5.602 Ohms
Mounting	Round - Extended Studs
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Stainless Steel
Shaft Type	Single Special Extension
Overall Length	11.58 in
Shaft Diameter	0.500 in
Shaft Extension	4.05 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720052570
Weight	28.00 LB
Packaged Length	15.56 IN
Packaged Width	13.75 IN
Packaged Height	13.22 IN
Country of Origin	China
