• Full stainless steel exterior promotes resistance to water and chemical corrosion.
• Double sealed bearings extend the lifetime of the motor by combating early signs of bearing failure.
• Stainless steel output shaft seals protect against external contaminants.
• Insulation systems deliver superior protection against voltage spikes.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	2 Hp
Output KW	1.5 kW
Voltage	115/230 V
Speed	1725 rpm
Service Factor	1.15
Frame	145TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	74 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	16.4/8.2 A
Power Factor	98
Duty	Continuous
Insulation Class	F
Design Code	N
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	.87 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Stainless Steel
Shaft Type	T
Overall Length	14.00 in
Frame Length	8.39 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720399521
Weight	52.00 LB
Packaged Length	15.35 IN
Packaged Width	10.00 IN
Packaged Height	10.00 IN
Country of Origin	China
