• Full stainless steel exterior promotes resistance to water and chemical corrosion.
• Double sealed bearings extend the lifetime of the motor by combating early signs of bearing failure.
• Stainless steel output shaft seals protect against external contaminants.
• Insulation systems deliver superior protection against voltage spikes.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	575 V
Speed	3450 rpm
Service Factor	1.15
Frame	56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	78.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	0.80 A
Power Factor	86
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6205
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	9.78 in
Shaft Diameter	0.625 in
Shaft Extension	1.875 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720110607
Weight	32.00 LB
Packaged Length	11.22 IN
Packaged Width	11.02 IN
Packaged Height	9.65 IN
Country of Origin	China
