• UL and CSA Listed, Meeting NEMA MG1 standards.
• Brush holder design provides easy access for motor maintenance.
• Permanent magnet design ensures higher motor efficiency.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Compatible with PWM or SCR type controllers.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	2 Hp
Output KW	1.5 kW
Voltage	180 V
Speed	1750 rpm
Service Factor	1.0
Frame	K145TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	78.8 %
Ambient Temperature	40 °C
Current	9.5 A
Duty	Continuous
Insulation Class	H
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Rigid C base
Overall Length	19.34 in
Frame Length	14.63 in
Shaft Diameter	0.875 in
Shaft Extension	2.13 in
Torque	72 LB-IN

General Specifications

UPC	691720017081
Weight	86.00 LB
Packaged Length	23.38 IN
Packaged Width	12.38 IN
Packaged Height	10.75 IN
Country of Origin	United States of America
