• Premium efficient ratings
• Inverter rated
• Class F insulation system – 140 frame and higher
• Shielded ball bearings for direct coupled applications
• Rolled steel frame material designs
• Continuous duty
• Dynamically balanced rotors
• UL recognized and CSA certified

Nameplate Specifications

Phase	3
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	575 V
Speed	1750 rpm
Service Factor	1.15
Frame	145TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Thermostat
Efficiency	86.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	1.9 A
Power Factor	67.7
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6206
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	13.42 in
Frame Length	7.50 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720104156
Weight	35.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
