• Premium efficient ratings
• Inverter rated
• Class B insulation systems – 42, 48 and 56 frames
• Class F insulation system – 140 frame and higher
• Shielded ball bearings for direct coupled applications
• Rolled steel frame material designs
• Continuous duty
• Dynamically balanced rotors
• UL recognized and CSA certified

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	575 V
Speed	1760 rpm
Service Factor	1.15
Frame	143TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	85.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	1.3 A
Power Factor	68.5
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	N
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	20.5 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	12.67 in
Frame Length	6.75 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720104149
Weight	35.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
