• Full stainless steel exterior promotes resistance to water and chemical corrosion.
• Double sealed bearings extend the lifetime of the motor by combating early signs of bearing failure.
• Stainless steel output shaft seals protect against external contaminants.
• Insulation systems deliver superior protection against voltage spikes.

Nameplate Specifications

Phase	3
Output HP	1.50 & 1 Hp
Output KW	1.1 & 0.75 kW
Voltage	230/460 & 190/380 V
Speed	1750 & 1450 rpm
Service Factor	1.15 & 1.15
Frame	143TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	86.5 & 86.5 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	4.8/2.4 & 3.6/1.8 A
Power Factor	67.7
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6205
UL	Recognized
CSA	Y
CE	Y
IP Code	69
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	9.12 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Stainless Steel
Shaft Type	T
Overall Length	12.75 in
Frame Length	7.75 in
Shaft Diameter	0.875 in
Shaft Extension	2.12 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	VARIABLE 10:1

General Specifications

UPC	691720053508
Weight	59.00 LB
Packaged Length	17.94 IN
Packaged Width	13.06 IN
Packaged Height	12.88 IN
Country of Origin	United States of America
