• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Suitable for use on a VFD, 10:1 variable torque and 2:1 constant torque.
• Class F insulation(as noted) protects motor for a maximum temperature rating.
• 1.15 service factor on sinewave, 1.0 service factor on IGBT power.
• Double sealed ball bearings mechanically locked on shaft end.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	1.50 & 1 Hp
Output KW	1.1 & 0.75 kW
Voltage	230/460 & 190/380 V
Speed	3515 & 2935 rpm
Service Factor	1.15 & 1.0
Frame	143JM
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	84 & 85.5 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	4/2 & 3.4/1.7 A
Power Factor	83.5
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	M
Drive End Bearing Size	6206
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	2
Rotation	Reversible
Resistance Main	9.27 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	JM
Overall Length	15.49 in
Frame Length	8.06 in
Shaft Diameter	0.875 in
Shaft Extension	4.28 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 2:1

General Specifications

UPC	691720048344
Weight	37.00 LB
Packaged Length	19.00 IN
Packaged Width	10.88 IN
Packaged Height	9.75 IN
Country of Origin	Mexico
