• Suitable for 220/380 volt, 50 Hz, or 440 volt, 50 Hz, three phase power
• Torques exceed NEMA performance for Design B motors
• Class F insulation
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	220/380/440 V
Speed	1440 rpm
Service Factor	1.15
Frame	145TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	75.5 %
Ambient Temperature	40 °C
Frequency	50 Hz
Current	5.8/3.3/2.9 A
Power Factor	68
Duty	Continuous
Insulation Class	F
Design Code	NO DESIGN CODE
KVA Code	K
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	54
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	2.53 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	12.42 in
Frame Length	6.50 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720016879
Weight	40.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
