• Motor pivots on rod for belt tensioning
• Extra high breakdown torques for maximum cutting power
• 3/4” Dia. Shaft, 1-3/4” long with keyway
• Includes 54 inch cord
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	4 Hp
Output KW	3.0 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1
Frame	145Y
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	84 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	17.6 A
Power Factor	94
Duty	Saw
Insulation Class	F
Design Code	NO DESIGN CODE
KVA Code	H
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Fixed Counterclockwise
Resistance Main	.52 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Overall Length	12.86 in
Frame Length	8.50 in
Shaft Diameter	0.750 in
Shaft Extension	1.75 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720016497
Weight	51.00 LB
Packaged Length	17.94 IN
Packaged Width	13.06 IN
Packaged Height	12.88 IN
Country of Origin	United States of America
