• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Suitable for use on a VFD, 10:1 variable torque and 2:1 constant torque.
• Class F insulation(as noted) protects motor for a maximum temperature rating.
• 1.15 service factor on sinewave, 1.0 service factor on IGBT power.
• Double sealed ball bearings mechanically locked on shaft end.
• LEESON® motors. Motors and solutions at our core™
• Operational at 115/208-230 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	1
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	115/230 V
Speed	1740 rpm
Service Factor	1.15
Frame	145JM
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	79 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	17.2/8.6 A
Power Factor	73
Duty	Continuous
Insulation Class	B
Design Code	L
KVA Code	J
Drive End Bearing Size	6206
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	1.32 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	JM
Overall Length	14.91 in
Frame Length	7.50 in
Shaft Diameter	0.875 in
Shaft Extension	4.21 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720016411
Weight	48.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
