• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Cradle base offers flexibility when mounting and repositioning the motor.
• Suitable for variable torque applications.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	2 & 0.50 Hp
Output KW	1.5 & 0.37 kW
Voltage	208-230 & 208-230 V
Speed	1725 & 850 rpm
Service Factor	1.0 & 1.0
Frame	145T
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	78.5 & 66 %
Ambient Temperature	40 °C
Frequency	60 & 60 Hz
Current	6.4 & 2.6 A
Power Factor	70.6
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	2.68 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	12.43 in
Frame Length	6.50 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720016350
Weight	38.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
