• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double-shielded bearings extend the service life of the motor.
• Fully gasketed frame prevents dust entry.
• High breakdown torque allows for optimum cutting power.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	3 Hp
Output KW	2.2 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1
Frame	145TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Manual
Efficiency	81.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	13.0 A
Power Factor	91
Duty	Continuous
Insulation Class	F
Design Code	L
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Selective Counterclockwise
Resistance Main	.52 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	14.43 in
Frame Length	8.50 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720016121
Weight	56.00 LB
Packaged Length	17.94 IN
Packaged Width	13.06 IN
Packaged Height	12.88 IN
Country of Origin	United States of America
