• UL recognized component listing and CSA certification ensures the product is safe for use.
• High starting torque on start-up, to achieve a higher starting load required in air compressor applications.
• Capacitor start or capacitor run for low-amp, high-efficiency, as noted.
• Heavy-duty construction ensures motor durability.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	5 Hp
Output KW	3.7 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1
Frame	145T
Enclosure	Drip Proof
Thermal Protection	Manual
Efficiency	82.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	20.8 A
Power Factor	95
Duty	Continuous
Insulation Class	F
Design Code	L
KVA Code	E
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Selective Clockwise
Resistance Main	.52 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	13.20 in
Frame Length	8.00 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720015704
Weight	49.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
