• Threaded jet pump motor shaft
• Vertical Shaft down design
• Rain canopy provided
• Epoxy painted
• Neoprene shaft flinger
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	2 Hp
Output KW	1.5 kW
Voltage	460 V
Speed	3550 rpm
Service Factor	1.5
Frame	56J
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Automatic
Efficiency	85.7 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.9 A
Power Factor	76.5
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	S
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Reversible
Resistance Main	3.83 Ohms
Mounting	Round
Motor Orientation	Shaft Down
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	15.93 in
Frame Length	8.75 in
Shaft Diameter	0.625 in
Shaft Extension	2.56 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720053683
Weight	35.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
