• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double-shielded bearings extend the service life of the motor.
• Extended shaft with wrench flats for manual jogging of auger.
• Manual-reset thermal protector (as noted) protects against motor overload.

Nameplate Specifications

Phase	1
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	115/208-230 V
Speed	1725 rpm
Service Factor	1.15
Frame	56NY
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Manual
Efficiency	77 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	14.5/7.1-7.3 A
Power Factor	85
Duty	Continuous
Insulation Class	B
KVA Code	K
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	SM
Poles	4
Rotation	Counterclockwise/Clockwise
Mounting	N/R
Motor Orientation	Any
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	14.51 in
Shaft Extension	.625 X 1.88 - 1.50 FLAT & 1.38 KEY 90 DEG APART in

General Specifications

UPC	691720003947
Weight	44.00 LB
Packaged Length	19.25 IN
Packaged Width	11.00 IN
Packaged Height	9.50 IN
Country of Origin	Mexico
