• All cast iron construction
• Stearns® high cycle brakes
• Manual release lever on brakes
• UL and CSA recognized construction
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	230 V
Speed	1760 rpm
Service Factor	1
Frame	56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	85.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.2 A
Power Factor	75
Duty	Continuous
Insulation Class	H
Design Code	B
KVA Code	N
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	17.8 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball / Heat Stabilized
Opp Drive End Bearing	Ball / Heat Stabilized
Frame Material	Cast Iron
Shaft Type	NEMA 56
Overall Length	16.10 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720003459
Weight	56.00 LB
Packaged Length	19.69 IN
Packaged Width	12.31 IN
Packaged Height	12.62 IN
Country of Origin	United States of America
