• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double-shielded bearings extend the service life of the motor.
• Extended shaft with wrench flats for manual jogging of auger.
• Manual-reset thermal protector (as noted) protects against motor overload.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	1 Hp
Output KW	0.75 kW
Voltage	115/230 V
Speed	1725 rpm
Service Factor	1
Frame	56
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Manual
Efficiency	74 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	14.0/7.0 A
Power Factor	63
Duty	Continuous
Insulation Class	F
Design Code	N
KVA Code	K
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	54
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	1.8 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	11.27 in
Frame Length	6.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720011010
Weight	38.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
