• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Cradle base offers flexibility when mounting and repositioning the motor.
• Suitable for variable torque applications.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.50 & 0.22 Hp
Output KW	0.37 & 0.16 kW
Voltage	115 & 115 V
Speed	1725 & 1140 rpm
Service Factor	1.0 & 1.0
Frame	56H
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	61.7 & 49.6 %
Ambient Temperature	40 °C
Frequency	60 & 60 Hz
Current	7.8 & 4.6 A
Power Factor	67
Duty	Continuous
Insulation Class	B
Design Code	NO DESIGN CODE
KVA Code	N
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	12
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Resilient Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	12.32 in
Frame Length	6.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720010402
Weight	36.00 LB
Packaged Length	14.44 IN
Packaged Width	7.94 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
