• Automatic reset thermal protector prevents overheating.
• Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
• Vertical/horizontal mounting for proper placement of the fan within airflow.
• LEESON® motors. Motors and solutions at our core™
• Operational at 208-230/460 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	3
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	230/460 V
Speed	1140 rpm
Service Factor	1.15
Frame	56Y
Enclosure	Drip Proof Air Over
Thermal Protection	Automatic
Efficiency	79 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.6/2.8 A
Power Factor	68
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	J
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	6
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Round Belly Band
Motor Orientation	Shaft Up
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Overall Length	15.06 in
Frame Length	7.50 in
Shaft Diameter	0.625 in
Shaft Extension	3.75 in
Assembly/Box Mounting	F1/F2 CAPABLE

General Specifications

UPC	691720009635
Weight	45.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
