• 303 stainless steel shaft resist corrosion
• Lubricated spring loaded contact seals prevent moisture from entering the motor
• Patented “V” ring Forsheda seal deflects water
• Double sealed, oversize bearings with high temp lubricant
• Exterior and interior components protected against moisture, acids, alkalies and oil
• 304 stainless steel conduit box cover and fan cover
• Repositionable drain plugs for use in multiple mounting positions
• Nylon seals at bolt heads for superior sealing
• Machined fits throughout
• Stainless steel fan guard; Stainless steel data plate; USDA approved white epoxy finish

Nameplate Specifications

Output HP	1 Hp
Output KW	0.75 kW
Voltage	24 V
Speed	1800 rpm
Service Factor	1.0
Frame	S56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	81.3 %
Ambient Temperature	40 °C
Current	39.0 A
Duty	Continuous
Insulation Class	H
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Rigid C base
Overall Length	13.82 in
Frame Length	6.47 in
Shaft Diameter	0.625 in
Shaft Extension	2.06 in
Torque	35 LB-IN

General Specifications

UPC	691720100240
Weight	34.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
