• Performance matched for continuous duty service.
• Rugged die cast aluminum gear housing supplies maximum gear and bearing support.
• Heavy duty industrial oil seals keep lubricant in and dirt out.
• All gearing designed and rated to AGMA Class 9 Standards, and to withstand momentary shock overload of 200%.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	90 V
Speed	18 rpm
Service Factor	1
Frame	48Y
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	66.9 %
Ambient Temperature	40 °C
Current	5.0 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	16.31 in
Frame Length	5.97 in
Shaft Diameter	0.750 in
Shaft Extension	1.5 in
Torque	1112 LB-IN

General Specifications

UPC	691720007129
Weight	44.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
