• Cast aluminum conduit box
• Terminal board provided for connections
• All metric fasteners
• Easy brush access for field service
• Oversize brushes for extended life
• High strength rolled steel frame
• Die cast aluminum endshields with steel bearing inserts
• Permanently lubricated sealed ball bearings
• Reversible rotation; Simple 2 lead connection; Convenient wiring access
• Tachometer mounting kits available for 71 and 80 frames only

Nameplate Specifications

Output KW	1.1 kW
Voltage	180 V
Speed	3000 rpm
Service Factor	1
Frame	80
Thermal Protection	No Protection
Efficiency	83.6 %
Ambient Temperature	40 °C
Current	7.0 A
Duty	S1
Insulation Class	F
Drive End Bearing Size	6204
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Overall Length	14.15 in
Frame Length	6.47 in
Shaft Diameter	0.750 in
Shaft Extension	2.05 in
Torque	21 LB-IN

General Specifications

UPC	691720006955
Weight	45.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
